Contractor Tools & Spec Downloads
Material Estimating & Product Specs - Everything You Need on One Page
Run an instant coverage calculation before you quote. Then pull the datasheet for whichever product you're specifying - specs, colours, certifications, all in one PDF.
Accurate to the carton
Coverage rates come directly from manufacturer spec sheets - not estimates. We update them whenever Kaycan or Mitten publishes a revision.
Print-ready PDF datasheets
Every datasheet is generated on demand. You get current specs, colour swatches, profiles, and certifications - no stale files, no account needed.
Metric or imperial
Switch between feet and centimetres at any point. The calculator converts your existing inputs automatically so nothing gets lost.
Estimating Tool
Free Siding & Soffit Coverage Calculator
Enter your wall or overhang dimensions, select a product, and get an instant carton count - waste factor and opening deductions built in.
Material Coverage Calculator
Estimate carton quantities for siding, soffit, and cladding
1 · Select Product
Coverage: 200 sq ft per carton
2 · Wall Dimensions
3 · Deduct Openings
Standard window = 12 sq ft · Standard door = 21 sq ft. Many contractors omit small windows to keep a safety buffer.
4 · Waste Factor
5 · Trim
A plain rectangular house has 4 outside corners. Starter strip runs along the base of every wall above. Outside corners run the height of your tallest wall. J-channel goes around each window you deducted, and across the head and both sides of each door. Results are in linear feet, because piece lengths differ by line.
Results
Enter wall dimensions to see your estimate
Estimate only. Results are based on manufacturer-published coverage rates and do not account for on-site variables such as wall geometry, cut patterns, installer technique, or regional availability. Always verify quantities with your Pro Materials sales rep before placing an order. Exterior Pro Materials assumes no liability for over- or under-ordering based on these figures.
Step-by-Step
How to Run an Estimate
Pick the product
Choose material type - vinyl, cedar shake, stone, metal, or soffit - then select the specific product. Coverage rate loads automatically.
Enter wall sizes
Type width × height for each wall in feet or cm. Hit + to add more walls. Mix and match - the calculator sums them.
Deduct openings
Add window and door counts. Use the custom field for oversized openings like garage doors or picture windows.
Set waste factor
10% for clean square walls, 15% if there are cuts around corners, 20% for gable ends or diagonal patterns.
Read your number
The results show net and gross area, the order in squares and cartons rounded up, and the trim runs in linear feet. Send the list straight to a quote request.
Spec Downloads
Product Datasheets
Full specs, profile dimensions, colour options, and installation notes - all in one print-ready PDF. Search by product name, brand, or category.
147 datasheets available
Aluminum Siding & Cladding
3 productsAluminum Trim & Coil
5 productsCedar Shake & Shingle Siding
7 productsEavestroughs & Downspouts
11 productsEngineered Wood Siding
8 productsExterior Shutters & Accents
4 productsExterior Trim
4 productsFibre Cement Siding
6 productsHorizontal Vinyl Siding
9 productsHouse Wrap & Insulation
8 productsInterior Wall Panels
5 productsLandscaping & Pavers
7 productsPVC & Vinyl Trim
15 productsRailings & Fencing
6 productsRoof & Gable Vents
4 productsSoffit & Fascia
7 productsSteel & Metal Panel Siding
8 productsStone Veneer & Cladding
8 productsTools & Equipment
5 productsVertical Vinyl Siding
3 productsVinyl Shingles & Shakes
4 productsVinyl Skirting
2 productsWindows
6 productsCommon Questions
Frequently Asked Questions
How do I calculate how much vinyl siding I need?
Measure the width and height of each wall in feet, multiply them, and add the walls together. Deduct about 12 sq ft per 3 x 4 ft window and 21 sq ft per 3 x 7 ft door. Add a waste factor of 10 to 20 percent. Then divide by the coverage per carton for your product and round up. Most vinyl cartons cover 100 or 200 sq ft. The calculator above does each step and shows the working.
Is a square of siding 100 sq ft?
Yes. A square is 100 square feet of wall, and Kaycan's estimating method divides the wall area by 100 to get the number of squares. Cartons are sized in squares. The standard Kaycan D4 and D5 cartons hold 200 sq ft, or two squares. Richmond, Montebello, Mitten West Ridge and Kaycan's vertical board and batten lines hold one. The calculator shows your order in squares as well as cartons.
What waste factor should I use for vinyl siding?
Kaycan's estimating method adds 10 percent for waste. Use 10 percent for clean rectangular walls and 15 percent for a moderate number of cuts around windows and corners. Use 20 percent for gable ends, diagonal runs or irregular walls. Running short mid-job costs more than a carton left over.
How many square feet does a carton of Kaycan or Mitten siding cover?
Standard D4 and D5 profiles (Hardwood Valley II, Timberlake, Verona) cover 200 sq ft per carton, and Prova and the Timberlake D4.5 and T3 cover 198. Richmond (D6), Mitten West Ridge (D8) and Montebello insulated siding cover 100 sq ft per carton. The calculator uses the manufacturer's rate for each product.
Do I need to deduct windows and doors from my siding calculation?
The calculator deducts 12 sq ft for each 3 x 4 ft window and 21 sq ft for each 3 x 7 ft door. Some contractors leave small windows in as a buffer for cuts and repairs. Kaycan's estimating method for Hardwood Valley II does not deduct openings at all. To leave them in, enter 0 windows and doors.
How does the calculator count starter strip, J-channel and corners?
In linear feet. Starter strip runs along the base of every wall you enter. Outside corners run the height of your tallest wall. J-channel goes around the windows and doors you deducted: 14 ft around each 3 x 4 window, and 17 ft across the head and both sides of each 3 x 7 door. Piece lengths differ by line, so we convert those figures to pieces for your chosen product on the quote.
Can the calculator handle soffit and skirting runs?
Yes. On the Soffit & Skirting tab, enter the overhang depth and the linear footage of each run separately. Panel soffit is counted in whole rows and whole panels, because a panel cannot be cut down its width to fill a shallow eave. A 10 or 15 percent waste allowance is then added.
What products are included in the coverage calculator?
Siding: Kaycan and Mitten horizontal and vertical vinyl siding, and MAC steel siding. Shakes and shingles: NovikShake, CertainTeed, Foundry and Mitten. Stone veneer: NovikStone, GenStone, Kaycan Versetta Stone and STONEfaçade. Soffit and skirting: Kaycan aluminum and vinyl soffit, Mitten vinyl soffit, and Mitten PleasantView vinyl skirting.
Where do I download product datasheets for Mitten, Kaycan, or Novik?
Use the Product Datasheets section on this page. Filter by brand, find your product, and download a print-ready PDF with specifications, profile dimensions, colours, certifications and installation notes. No login required.
Still have questions about quantities or specs?
Our team quotes exterior materials for contractors across York Region, the GTA, Simcoe County and Durham Region. Give us a call or send a message - we're happy to review your takeoff.
